CPU
Dual AMD EPYC™ 9005 Series Processor Family
Dimensions
438mm (W) x 87mm (H) x 770mm (D)
17.24inch (W) x 3.43inch (H) x 30.31inch (D)
Memory
Memory Type: Up to 6000 MT/s DDR5 RDIMM
DIMM Slots: 24 DIMM Slots
Storage
Front:
•24 * 2.5” SATA/SAS
•24 * 2.5” SATA/SAS4/NVMe U.2 PCIe Gen5
•12 * 3.5” SATA/SAS4/NVMe U.2 PCIe Gen5
•12 * 3.5” SATA/SAS
Rear:
•2 * 2.5” SATA/SAS
•2 * 2.5” SATA/SAS4/NVMe U.2 PCIe Gen5
Internal:
•2 * M.2 (Type 2280)
PCIe Slot
General SKU:
2 * PCIe Gen5 x16 FHFL
2 * PCIe Gen5 x8 FHFL
2 * PCIe Gen5 x8 FHHL
1 * PCIe Gen5 x8 HHHL
1 * PCIe Gen5 x16 OCP 3.0
1 * PCIe Gen5 x8 OCP 3.0
GPU SKU:
2 * PCIe Gen5 x16 FHFL(Double Width)
2 * PCIe Gen5 x16 FHHL
1 * PCIe Gen5 x8 HHHL
1 * PCIe Gen5 x16 OCP 3.0
1 * PCIe Gen5 x8 OCP 3.0
Security
TPM 2.0 (optional)
NIST SP 800-193 (optional)
Power Supply
•1200W 1+1 Redundant, Platinum
•1300W 1+1 Redundant, Titanium
•1600W 1+1 Redundant, Platinum/Titanium
•2000W 1+1 Redundant, Platinum/Titanium
•2400W 1+1 Redundant, Titanium
