CPU
Dual 3rd Gen Intel® Xeon® Scalable Processors
Dimensions
432.4mm (W) x 680.4mm (D) x 174.3mm (H)
17.02inch (W) x 26.79inch (D) x 6.86inch (H)
Memory
DIMM Type: DDR4 RDIMM up to 3200 MT/s
DIMM Count: 16 DIMM Slots
Storage
Front:
• 24 * 3.5" SATA/SAS
Rear:
• 4 * 2.5" SATA/SAS/NVMe U.2 (7mm)
• 12 * 3.5" SATA/SAS
For U.2 drives:
Intel® Virtual RAID on CPU (VROC) RAID 0, 1, 10, 5
PCIe Slot
• 1 * FHFL PCIe Gen4 x16
• 2 * FHHL PCIe Gen4 x16
• 2 * FHHL PCIe Gen4 x8
• 1 * OCP 2.0 (Connector A)
Security
TPM 2.0 (optional)
Power Supply
1200W 1+1 Redundant, Platinum
1300W 1+1 Redundant, Titaninum
I/O Ports
Front:
•1 * UID Button with LED
•1 * Power Button with LED
•1 * Reset Button
•2 * USB 3.2 Gen1 port
Rear:
•1 * VGA port
•1 * UID Button with LED
•2 * USB 3.2 Gen1 ports
•1 * Serial port
•2 * 1GbE
•1 * 1GbE Management port
Internal:
•1 * USB 3.2 Gen1 port Type-A
