Specifications
CPU
Dual 6th Gen Intel® Xeon® Scalable Processors, up to 350W
Dimensions
438mm (W) x 87mm (H) x 770mm (D)
17.24inch (W) x 3.43inch (H) x 30.31inch (D)
Memory
Memory Type: DDR5 RDIMM(Up to 6400MT/s)
DIMM Slots: 32 DIMM Slots
Storage
Front:
•24 * 2.5” SATA/SAS
•24 * 2.5” SATA/SAS4/NVMe U.2 PCIe Gen5
•12 * 3.5” SATA/SAS4/NVMe U.2 PCIe Gen5
•12 * 3.5” SATA/SAS
All drives support Hot-swap
Rear:
•2 * 2.5” SATA/SAS
•2 * 2.5” SATA/SAS/NVMe U.2 PCIe Gen5
All drives support Hot-swap
Internal:
•2 * M.2 (PCIe Gen5 Type 2280)
PCIe Slot
General SKU:
•2 *PCIe Gen5 x16 FHFL
•2 *PCIe Gen5 x8 FHFL
•2 * PCIe Gen5 x8 FHHL
•1 * PCIe Gen5 x8 HHHL
•1 * PCIe Gen5 x16 OCP 3.0
•1 * PCIe Gen5 x8 OCP 3.0
GPU SKU:
•2 * PCIe Gen5 x16 FHFL (Double Width)
•2 * PCIe Gen5 x16 FHHL
•1 * PCIe Gen5 x8 HHHL
•1 * PCIe Gen5 x16 OCP 3.0
•1 * PCIe Gen5 x8 OCP 3.0
Security
TPM 2.0 (optional)
PFR 3.0 (optional)
Power Supply
1200W 1+1 Redundant, Platinum PSU
1300W 1+1 Redundant, Titanium PSU
1600W 1+1 Redundant, Platinum/Titanium PSU
2400W 1+1 Redundant, Titanium PSU
I/O Ports
Front:
•1 * VGA port
•1 * UID Button
•1 * Power / Reset Button
•1 * USB 3.2 Gen1 port
•1 * USB 2.0 port
Rear:
•1 * Mini Display port
•1 * Power Button
•1 * UID Button
•2 * USB 3.2 Gen1 ports
•1 * 1GbE Management port
