Specifications
CPU
Single AMD EPYC™ 9005 Series Processor Family
Dimensions
438mm (W) x 87mm (H) x 735mm (D)
17.24inch (W) x 3.43inch (H) x 28.94inch (D)
Memory
Memory Type: Up to 6000 MT/s DDR5 RDIMM
DIMM Count: 12 DIMM Slots
Storage
Front:
•24 * 2.5” SATA/SAS4 drives
•16 * 2.5” NVMe/SATA/SAS4 + 8 * 2.5" SATA/SAS4 drives
•12 * 3.5” NVMe/SATA/SAS4 drives
Rear:
•2 * 2.5” NVMe/SATA/SAS4 drives
PCIe Slot
2 * FHFL (Double Width) PCIe Gen5 x16
1 * FHHL PCIe Gen5 x16
1 * LP PCIe Gen5 x16
2 * FHHL PCIe Gen5 x8
2 * LP PCIe Gen5 x8
1 * OCP 3.0 PCIe Gen5 x16
Security
TPM 2.0 (optional)
NIST SP 800-193 (optional)
Power Supply
•1200W 1+1 Redundant, Platinum
•1300W 1+1 Redundant, Titanium
•1600W 1+1 Redundant, Platinum/Titanium
•2400W 1+1 Redundant, Titanium
I/O Ports
Front:
•1 * VGA port
•1 * UID button
•1 * Power button
•1 * Reset button
•2 * USB 3.2 Gen1 port
Rear:
•1 * Mini display port
•1 * Power button
•1 * UID button
•2 * USB 3.2 Gen1 ports
•1 * 1GbE management port
Internal:
•1 * USB 3.2 Gen1 port
